Wings assembly
USER MANUAL
41
Insert the aileron using 20x30mm polyester hinges or ones made from
another material, similar to the elevator. Then, using a slightly heated
soldering iron, attach M3 threaded inserts designed for servo cover
mounting. Set the servo so that the control horn protrudes through
the opening in the servo cover, glue it in place using hot glue, and
cover it. Then, connect the servo to the aileron using a pushrod,
similar to the elevator.
Note: when gluing the aileron control horn, one of the hinges may be
obstructive. You can simply pierce that hinge with a knife when
securing the control horn or skip one of the hinges
