Tail assembly
USER MANUAL
35
Now you can mount the elevator. Glue it together
from two halves, and then use three polyester
hinges with dimensions of 20x30mm and glue them
into the designed slots. You can use ready-made
hinges or cut them from flexible material, or even
3D print them from a material like TPU.
Note that the right half of the elevator
has a slot for the control horn. It is
recommended to use a plastic control
horn available in hobby stores and
connect it to the servo using a pushrod
of your choice. You can use snaps, bend
a Z-bend on a wire, or employ other
fastening techniques.
