Tail assembly
USER MANUAL
32
At this stage, it is necessary to attach the elevator servo and the tail boom.
Inside the tail, there is a designed channel for the servo cable. While
installing the servo, guide the cable through that channel and into the tail
boom. The cable will likely be too short to reach the fuselage, so you may
need to use an extension or manually lengthen the cables. To enable the tail
boom installation, it is necessary to cut a "groove" approximately 7cm long
from the end, so it reaches around the area where the servo is located. This
can be done with a Dremel or by carving it with a file. Once the tail boom is
prepared in this way, insert it all the way and glue it in place.
It’s best to use 5 min epoxy glue.
7cm long groove
Internal channel for servo cable
