FLIR A15 User Manual

Focusing the camera
8
8.1 Focusing cameras with 5, 9, 13, and 19 mm lenses
8.1.1 Necessary tools
Focus adjustment tool (included in the package for cameras with 5, 9, 13, and 19 mm
lenses).
8.1.2 Procedure
Follow this procedure:
1. Note the four pegs on the inside of the focus adjustment tool.
2. Align the four pegs with the corresponding slots on the front of the lens, and push the
focus adjustment tool into position.
3. Rotate the lens.
#T559770; r. AF/30726/30726; en-US
13
