Technical data11
11.16 FLIR A5 f=9 mm (7.5 Hz)
P/N: 64209-0101
Rev.: 30724
General description
The FLIR A5 has features and functions that make it the natural choice for anyone who uses PC software
to solve problems and for whom 80 × 64 pixel resolution is sufficient.
Among its main features are GigE Vision and GenICam compliance, which makes it plug-and-play when
used with software packages such as IMAQ Vision and Halcon.
Key features:
• Very affordable.
• Compact (40 mm × 43 mm × 106 mm).
• GigE Vision and GenICam compliant.
• GigE Vision lockable connector.
• PoE (power over Ethernet).
• 8-bit 80 × 64 pixel images streamed at 7.5 Hz, signal linear.
• 14-bit 80 × 64 pixel images streamed at 7.5 Hz, signal and temperature linear.
• Synchronization between cameras possible.
• 1x+1x GPIO.
• Compliant with any software that supports GenICam, including National Instruments IMAQ Vision,
Stemmers Common Vision Blox, and COGNEX Vision Pro.
Typical applications:
• Automation and thermal machine vision.
• Entry level “high-speed” R&D.
Imaging and optical data
IR resolution 80 × 64 pixels
Thermal sensitivity/NETD < 0.05°C @ +30°C (+86°F) / 50 mK
Field of view (FOV)
25° × 20°
Focal length 9 mm (0.35 in.)
Spatial resolution (IFOV)
5.56 mrad
F-number 1.25
Image frequency 7.5 Hz
Focus Fixed
Detector data
Detector type
Focal plane array (FPA), uncooled VOX
microbolometer
Spectral range
7.5–13 µm
Detector pitch 50 µm
Detector time constant Typical 12 ms
Measurement
Object temperature range
• –25 to +135°C (–13 to 275°F)
• –40 to +550°C (–40 to +1022°F)
Accuracy ±5°C (±9°F) or ±5% of reading
#T559770; r. AF/30726/30726; en-US
69
