FLIR A15 User Manual

Technical data11
Measurement analysis
Atmospheric transmission correction Automatic, based on inputs for distance, atmos-
pheric temperature and relative humidity
Optics transmission correction Automatic, based on signals from internal sensors
Emissivity correction Variable from 0.5 to 1.0
Reflected apparent temperature correction Automatic, based on input of reflected temperature
External optics/windows correction Automatic, based on input of optics/window trans-
mission and temperature
Measurement corrections Global object parameters
Ethernet
Ethernet
Control and image
Ethernet, type
Gigabit Ethernet
Ethernet, standard IEEE 802.3
Ethernet, connector type RJ-45
Ethernet, communication GigE Vision ver. 1.2
Client API GenICam compliant
Ethernet, image streaming 8-bit monochrome @ 7.5 Hz
• Signal linear/ DDE
• Automatic/ Manual
• Flip H&V
14-bit 640 × 512 pixels @ 7.5 Hz
• Signal linear/ DDE
• Temperature linear
GigE Vision and GenICam compatible
Ethernet, power Power over Ethernet, PoE IEEE 802.3af class 0
Power
Ethernet, protocols
TCP, UDP, ICMP, IGMP, DHCP, GigEVision
Digital input/output
Digital input, purpose
General purpose
Digital input
1× opto-isolated, “0” <1.2 VDC, “1” = 2–25 VDC.
Digital output, purpose
General purpose output to ext. device (program-
matically set)
Digital output
1× opto-isolated, 2–40 VDC, max. 185 mA
Digital I/O, isolation voltage 500 VRMS
Digital I/O, supply voltage 2–40 VDC, max. 200 mA
Digital I/O, connector type 12-pole M12 connector (shared with Digital syn-
chronization and External power)
Synchronization in, purpose
Frame synchronization in to control camera
Synchronization in
1×, non-isolated
Synchronization in, type LVC Buffer @3.3V, “0” <0.8 V, “1”>2.0 V.
Synchronization out, purpose
Frame synchronization out to control another FLIR
Ax5 camera
Synchronization out
1×, non-isolated
#T559770; r. AF/30726/30726; en-US
82
