Technical data9
Set-up
Color palettes Color palettes (BW, BW inv, Iron, Rain)
Set-up commands Date/time, Temperature (°C/°F)
Storage of images
Storage media Built-in memory for image storage
File formats Standard JPEG, 16-bit measurement data
included
Ethernet
Ethernet Control and image
Ethernet, type 100 Mbps
Ethernet, standard IEEE 802.3
Ethernet, connector type RJ-45
Ethernet, communication TCP/IP socket-based FLIR proprietary
Ethernet, video streaming MPEG-4, ISO/IEC 14496-1 MPEG-4 ASP@L5
Ethernet, image streaming 16-bit 320 × 240 pixels @ 3 Hz
- Radiometric
Ethernet, power Power over Ethernet, PoE IEEE 802.3af class 0
Ethernet, protocols TCP, UDP, SNTP, RTSP, RTP, HTTP, ICMP, IGMP,
ftp, SMTP, SMB (CIFS), DHCP, MDNS (Bonjour),
uPnP
Digital input/output
Digital input, purpose
Image tag (start/stop/general), Input ext. device
(programmatically read)
Digital input
2 opto-isolated, 10–30 VDC
Digital output, purpose
Output to ext. device (programmatically set)
Digital output 2 opto-isolated, 10–30 VDC, max. 100 mA
Digital I/O, isolation voltage 500 VRMS
Digital I/O, supply voltage 12/24 VDC, max. 200 mA
Digital I/O, connector type
6-pole jackable screw terminal
Composite video
Video out
Composite video output, PAL and NTSC
compatible
Video, standard
CVBS (ITU-R-BT.470 PAL/SMPTE 170M NTSC)
Video, connector type
Standard BNC connector
Power system
External power operation The camera operates on 12/24 VDC, 9 W max.
(allowed range: 10-30 VDC) and heaters on 24
VDC, 25 W max. In total: 34 W.
External power, connector type 2-pole jackable screw terminal
Voltage Allowed range 10–30 VDC
Environmental data
Operating temperature range –25°C to +50°C (–13°F to +122°F)
Storage temperature range –40°C to +70°C (–40°F to +158°F)
Humidity (operating and storage) IEC 60068-2-30/24 h 95% relative humidity +25°C
to +40°C (+77°F to +104°F)
#T559794; r. AJ/35709/35709; en-US
16
