Technical data9
9.13 FLIR A315f 90°
P/N: 61201-1205
Rev.: 35207
General description
The main purpose of the housing on the FLIR A315f is to increase the environmental specification of
the standard FLIR A315 to IP66 without affecting any of the features available in the camera itself.
The built-in FLIR A315 camera has features and functions that make it the natural choice for anyone
who uses PC software to solve problems and for whom 320 × 240 pixel resolution is sufficient. Among
its main features are GigE Vision and GenICam compliance, which makes it plug-and-play when used
with software packages such as IMAQ Vision and Halcon.
Key features:
• Encapsulation to IP66.
• Affordable.
• GigE compliant.
• GenICam compliant.
• Trigg/synchronization/GPIO.
• 16-bit 320 × 240 pixel images at 60 Hz, signal, temperature linear, and radiometric.
• Compliant with any software that supports GenICam, including National Instruments IMAQ Vision
and Stemmers Common Vision Blox.
Typical applications:
Imaging and optical data
IR resolution 320 × 240 pixels
Thermal sensitivity/NETD < 0.05°C @ +30°C (+86°F) / 50 mK
Field of view (FOV)
90° × 73°
Minimum focus distance 20 mm (0.79 in.)
Focal length 4 mm (0.157 in.)
Spatial resolution (IFOV) 6.3 mrad
Lens identification Automatic
F-number 1.3
Image frequency 60 Hz
Focus Automatic or manual (built in motor)
Detector data
Detector type Focal plane array (FPA), uncooled
microbolometer
Spectral range
7.5–13 µm
Detector pitch 25 µm
Detector time constant Typical 12 ms
Measurement
Object temperature range
• –20 to +120°C (–4 to +248°F)
• 0 to +350°C (+32 to +662°F)
Accuracy ±4°C (±7.2°F) or ±4% of reading
Measurement analysis
Atmospheric transmission correction Automatic, based on inputs for distance, atmos-
pheric temperature and relative humidity
Optics transmission correction Automatic, based on signals from internal sensors
Emissivity correction Variable from 0.01 to 1.0
Reflected apparent temperature correction Automatic, based on input of reflected
temperature
#T559794; r. AJ/35709/35709; en-US
47
