Technical data9
Measurement analysis
External optics/windows correction Automatic, based on input of optics/window trans-
mission and temperature
Measurement corrections
Global object parameters
Ethernet
Ethernet Control and image
Ethernet, type Gigabit Ethernet
Ethernet, standard IEEE 802.3
Ethernet, connector type RJ-45
Ethernet, communication
TCP/IP socket-based FLIR proprietary and GenI-
Cam protocol
Ethernet, image streaming 16-bit 320 × 240 pixels @ 60 Hz
- Signal linear
- Temperature linear
- Radiometric
GigE Vision and GenICam compatible
Ethernet, protocols
TCP, UDP, SNTP, RTSP, RTP, HTTP, ICMP, IGMP,
ftp, SMTP, SMB (CIFS), DHCP, MDNS (Bonjour),
uPnP
Digital input/output
Digital input, purpose Image tag (start, stop, general), Image flow con-
trol, (stream on/off), Input ext. device (program-
matically read)
Digital input
2 opto-isolated, 10–30 VDC
Digital output, purpose
Output to ext. device (programmatically set)
Digital output
2 opto-isolated, 10–30 VDC, max. 100 mA
Digital I/O, isolation voltage 500 VRMS
Digital I/O, supply voltage 12/24 VDC, max. 200 mA
Digital I/O, connector type 6-pole jackable screw terminal
Power system
External power operation The camera operates on 12/24 VDC, 9 W max.
(allowed range: 10-30 VDC) and heaters on 24
VDC, 25 W max. In total: 34 W.
External power, connector type 2-pole jackable screw terminal
Voltage
Allowed range 10–30 VDC
Environmental data
Operating temperature range –25°C to +50°C (–13°F to +122°F)
Storage temperature range –40°C to +70°C (–40°F to +158°F)
Humidity (operating and storage) IEC 60068-2-30/24 h 95% relative humidity +25°C
to +40°C (+77°F to +104°F)
EMC
• EN 61000-6-2 (Immunity)
• EN 61000-6-3 (Emission)
• FCC 47 CFR Part 15 Class B (Emission)
Encapsulation IP 66 (IEC 60529)
Bump 5 g, 11 ms (IEC 60068-2-27)
Vibration
2 g (IEC 60068-2-6)
