Technical data9
Ethernet
Ethernet, image streaming 16-bit 320 × 240 pixels @ 7-8 Hz
- Radiometric
Ethernet, power Power over Ethernet, PoE IEEE 802.3af class 0
Ethernet, protocols Ethernet/IP, Modbus TCP, TCP, UDP, SNTP, RTSP,
RTP, HTTP, ICMP, IGMP, ftp, SMTP, SMB (CIFS),
DHCP, MDNS (Bonjour), uPnP
Digital input/output
Digital input, purpose Image tag (start/stop/general), Input ext. device
(programmatically read)
Digital input 2 opto-isolated, 10–30 VDC
Digital output, purpose As function of ALARM, Output to ext. device (pro-
grammatically set)
Digital output 2 opto-isolated, 10–30 VDC, max. 100 mA
Digital I/O, isolation voltage 500 VRMS
Digital I/O, supply voltage 12/24 VDC, max. 200 mA
Digital I/O, connector type
6-pole jackable screw terminal
Composite video
Video out Composite video output, PAL and NTSC
compatible
Video, standard CVBS (ITU-R-BT.470 PAL/SMPTE 170M NTSC)
Video, connector type Standard BNC connector
Power system
External power operation The camera operates on 12/24 VDC, 9 W max.
(allowed range: 10-30 VDC) and heaters on 24
VDC, 25 W max. In total: 34 W.
External power, connector type 2-pole jackable screw terminal
Voltage
Allowed range 10–30 VDC
Environmental data
Operating temperature range –25°C to +50°C (–13°F to +122°F)
Storage temperature range –40°C to +70°C (–40°F to +158°F)
Humidity (operating and storage) IEC 60068-2-30/24 h 95% relative humidity +25°C
to +40°C (+77°F to +104°F)
EMC
• EN 61000-6-2 (Immunity)
• EN 61000-6-3 (Emission)
• FCC 47 CFR Part 15 Class B (Emission)
Encapsulation IP 66 (IEC 60529)
Bump 5 g, 11 ms (IEC 60068-2-27)
Vibration
2 g (IEC 60068-2-6)
Physical data
Weight 4.8 kg (10.6 lb.)
Size (L × W × H) 460 × 140 × 159 mm (18.1 × 5.5 × 6.3 in.)
Base mounting
Housing material Aluminum
#T559794; r. AJ/35709/35709; en-US
