FLIR A6700sc User Manual

7 – Specifications
A6700sc/A6750sc User’s Manual 40
Minimum
Resolution
480 nS
160 nS
Preset Sequencing
• N/A
Digital Video Output
Selectable:
• Raw digital video (14-bits)
• Gain and offset (NUC) corrected (14-bits)
• NUC with bad pixel replaced (14-bits)
7.4 Analog Video
Video Output
• NTSC or PAL composite
Data Output
Selectable
• Raw, uncorrected
• Corrected
AGC
Selectable
• DDE
• Plateau based equalization
• Linear equalization
AGC Filter
User controlled damping factor
User controlled update rate
Overlay
Available on analog output
Palettes
Selectable
• Grayscale
• Various color palettes
Zoom (Analog video)
Auto-selected
• x1 for 640x512
• x2 for 320x256 and 160x120 window sizes
Brightness and Contrast
(analog video)
User controlled to increase or decrease
7.5 Performance Characteristics
Power Consumption
FLIR PWR Supply @ 120V
AC
Continuous Cool Down: 50 VA
Continuous Normal: 41 VA

FLIR A6700sc Specifications

General

Resolution	640 x 512
Thermal Sensitivity/NETD	<20 mK
Sensor Type	Uncooled VOx Microbolometer
Detector Type	Focal Plane Array (FPA)
Pixel Pitch	17 µm
Interface	Gigabit Ethernet
Power Requirements	24 VDC
Operating Temperature	-15°C to 50°C
Storage Temperature	-40°C to 70°C
Spectral Range	7.5 – 14.0 µm
Lens Options	25 mm, 50 mm, 100 mm (others available)
Temperature Range	-20°C to +1500°C (-4°F to +2732°F) (in multiple ranges)
