FLIR Lepton 1.5 User Manual

FLIR LEPTON® Engineering Datasheet
The information contained herein does not contain technology as defined by the EAR, 15 CFR 772, is publicly available,
and therefore, not subject to EAR. NSR (6/14/2018).
Information on this page is subject to change without notice.
Lepton Engineering Datasheet, Document Number: 500-0659-00-09 Rev: 203
9
1.5 Key Specifications
Table 1- Key Specifications
All numbers are nominal unless tolerances are specified.
Available configurations
Part number
Array format
Horizontal field of view
Shutter
Thermal
radiometry
Distortion (barrel)
Scene Dynamic range
3
-
High gain (Low gain)
Pixel pitch
Lepton 1.5: 500-0643-00
80 x 60
50°
No
-
<8%
-10 °C to +140 °C
17 μm
Lepton 1.6: 500-0690-00
80 x 60
25°
No
-
<3%
-10 °C to +140 °C
17 μm
Lepton 2.0: 500-0659-01
80 x 60
50°
Yes
-
<8%
-10 °C to +140 °C
17 μm
Lepton 2.5: 500-0763-01
80 x 60
50°
Yes
Yes
<8%
-10 °C to +140 °C
(-10°C to 450°C)
17 μm
Lepton 3.0: 500-0726-01
160 x 120
57°
Yes
-
<13%
-10 °C to +140 °C
12 μm
Lepton 3.5: 500-0771-01
160 x 120
57°
Yes
Yes
<13%
-10 °C to +140 °C
(-10°C to 400°C)
12 μm
Overview
Sensor technology
Uncooled VOx microbolometer
Spectral range
Longwave infrared, 8 μm to 14 μm
Video scan
Progressive
Effective frame rate
4
8.7 Hz (exportable)
Thermal sensitivity
<50 mK (0.050°C)
Temperature compensation
Automatic. Output image independent of camera
temperature.
3
Scene Dynamic Range is specified at room temperature and may vary over ambient temperature. It is typically somewhat
reduced at lower operating temperature.
4
Lepton 1.5, 1.6, 2.0, 2.5 stream video at 26Hz with every 3 frames repeated (effectively 8.7Hz). Lepton 3.0 and 3.5 stream
segments of the images with effectively full frames at 8.7Hz. In this document, when referring to number of frames the
frame rate 26Hz is understood.

FLIR Lepton 1.5 Specifications

General

Brand	FLIR
Model	Lepton 1.5
Category	Control Unit
Language	English
