Warning:Productgrounding
Beforeapplyingpowertothisproduct,
ensureithasbeencorrectlygrounded,in
accordancewiththeinstructionsprovided.
Warning:Positiveground
systems
Donotconnectthisunittoasystemwhich
haspositivegrounding.
4.4NMEA2000network
connection
YourSeaTalk
ng®
devicecanbeconnectedtoa
DeviceNet/NMEA2000network.
1.SeaTalk
ng®
device
2.SeaTalk
ng®
toDeviceNetadaptorcable
(A06045)
3.DeviceNetT-piece
4.NMEA2000backbone
Cablesandconnections
4.5SeaTalk
ng®
networkexample
Yourproductprovidesdatatootherdevicesonthe
SeaTalk
ng®
network.
1.SeaTalk
ng®
MFD
2.SeaTalk
ng®
VHFRadio
3.RS150GNSSReceiver
4.EvolutionEVsensor
5.SeaTalkPilotcontroller
6.ACU(ActuatorControlUnit)
7.SeaTalktoSeaTalk
ng®
converter
