2.1Documentinformation
Thisdocumentcontainsimportantinformation
relatedtotheinstallationofyourRaymarineproduct.
Thedocumentincludesinformationtohelpyou:
•planyourinstallationandensureyouhaveallthe
necessaryequipment;
•installandconnectyourproductaspartofawider
systemofconnectedmarineelectronics;
•troubleshootproblemsandobtaintechnical
supportifrequired.
Applicable products
This document is applicable to the following products:
PartnumberNameDescription
E70310
RS150SeaTalk
ng
GNSS(GPS-
/GLONASS)
Receiver
Documentillustrations
Yourproductmaydifferslightlyfromthatshown
intheillustrationsinthisdocument,dependingon
productvariantanddateofmanufacture.
Allimagesareprovidedforillustrationpurposesonly.
Productdocumentation
Thefollowingdocumentationisapplicabletoyour
product:
DescriptionPartnumber
RS150Installationinstructions
InstallationofaRS150andconnectiontoa
widersystemofmarineelectronics.
87271
RS150Mountingtemplate
MountingdiagramformountingaRS150.
87272
Operationinstructions
Fordetailedoperationinstructionsforyourproduct,
refertothedocumentationthataccompaniesyour
display.
2.2RS150productoverview
TheRS150isaSeaTalkng®GlobalNavigation
SatelliteSystems(GNSS)Receiver.TheRS150
providespositiondatatodevicesconnectedtothe
SeaTalkng®network.Whenusedinconjunctionwith
aSeaT alkandSeaT alkng®convertertheRS150can
alsoprovidepositiondatatoSeaT alkdevices.
TheRS150hasthefollowingfeatures:
•CompatiblewithGPSandGLONASSGNSS
systems
•BeiDouandGalileoready(supportedbyfuture
softwareupdate)
•Pole,Rail,SurfaceorBracketmountable
(mountingkitsavailable)
•10Hzrefreshrate
•NMEA2000compliant
•Lowpowerconsumption
•12VDCoperation(24Vprotection)
•WaterprooftoIPx6
SeaTalkng®
SeaTalkng®(NextGeneration)isanenhanced
protocolforconnectionofcompatiblemarine
instrumentsandequipment.Itreplacestheolder
SeaTalkandSeaTalk2protocols.
SeaTalkng®utilizesasinglebackbonetowhich
compatibleequipmentconnectusingaspur.Data
andpowerarecarriedwithinthebackbone.Devices
thathavealowdrawcanbepoweredfromthe
network,althoughhighcurrentequipmentwillneed
tohaveaseparatepowerconnection.
SeaTalkng®isaproprietaryextensiontoNMEA2000
andtheprovenCANbustechnology.Compatible
NMEA2000andSeaT alkandSeaTalk2devicescan
alsobeconnectedusingtheappropriateinterfaces
oradaptorcablesasrequired.
