4.84in
122.9mm
2.83in
72mm
1.79in
45.4mm
1.68in
42.8mm
0.73in
18.7mm
For additional dimensions see page 1
Camera with Lens IR f=17mm (24°)
Camera with Lens IR f=10mm (42°)
Camera with Lens IR f=29mm (14°)
Camera with Lens IR Close-up 2x
Sheet
Drawing No.
Size
Check
Drawn by
Denomination
A3
2(4)
T129991
Basic dimensions FLIR T5xx
JOHE
2020-01-14
R&D Instruments
Modified
1 2 3 4 5 6 7 8 9 10
A
B
C
D
E
F
G
H
1 32 54
C
F
B
D
G
E
A
6
Rev
B
1:5
Scale
© 2016, FLIR Systems, Inc. All rights reserved worldwide. No part of this drawing may be reproduced, stored in a retrieval system, or transmitted in any form, or by any means, electronic, mechanical, photocopying, recording, or otherwise,
without written permission from FLIR Systems, Inc. Specifications subject to change without further notice. Dimensional data is based on nominal values. Products may be subject to regional market considerations. License procedures may apply.
Product may be subject to US Export Regulations. Please refer to exportquestions@flir.com with any questions. Diversion contrary to US law is prohibited.
