[7 — Technical specifications]
ThermaCAM™ PM575/595 Operator’s Manual
44
7 Technical specifications
7.1 General specifications
Object temperature measurement
range (PM595):
-40—+500 ºC (-40—+930 ºF), two ranges. Up to
+2000 ºC (+2700 ºF) with high temperature option.
Object temperature measurement
range (PM575):
-20—+500 ºC (-4—+930 ºF), two ranges. Up to
+1000 ºC (+1832 ºF) with high temperature option.
Measurement accuracy: ± 2 %
Thermal sensitivity: < 0.1 ºC
Field of view (F x V): See “Lens data” on page 48.
Detector type: Focal Plane Array (FPA), uncooled microbolometer,
320 x 240 pixels.
Spectral range: 7.5—13 µm, built-in atmosheric filter with cut-on
@ 7.5 µm.
Video output: Standard VHS or S-VHS.
Viewfinder: Colour LCD (TFT)
PC-card drive: One slot for Type II or Type III PC-cards. Either FLASH
cards or hard disks (ATA-compatible) can be used.
