[7.2.2 — Headset socket]
© FLIR Systems AB – Publ. No. 557 369 – Ed. A
47
7.2.2 Headset socket
Pin
[1] Headphone, +, impedance >350 ohm. Max swing 2.3 Vpp
[2] Head phone, -
[3] Microphone, +, electorate type, phantom feed 5 VDC, 1 mA,
max. swing 30 mVpp
[4] Microphone, -
[5] N/C
7.2.3 Video socket
Pin
[1] Composite video
[2] N/C
[3] N/C
[4] N/C
[5] Power out
[6] Ground
[7] Ground
7.2.4 Battery charger
CE certified.
Input: 100–240 VAC, 50 W
Frequency: 50/60 Hz
Output: 11–18 VDC, 1.8 A.
Weight: 0.7 kg (1.55 lbs)
Maximum output: 36 W
Size: 230 x 150 x 72 mm (9.06" 5.90" 2.83")
