Installation Guide
5
www
Specifications
Specifications:
Description of the available models:
• CoRe+V2: Level 2 charging station equiped with display and card reader
• CoRe+VBV2: Level 2 charging station without display and without card reader
• CoRe+PSV2: Level 2 charging station equiped with display, car reader and PowerSharing firmware
Output connector: J-1772 compliant
Split phase 120/240 VAC supply or 3 phase 120/208 VAC (must be protected by a 40 A breaker or
fuse) Maximum output current (power):
• CoRe+V2 and CoRe+VBV2: 30A (7.2 kW @ 240 V or 6.3 kW @ 208 V)
• CoRe+PSV2: Dynamically controlled by a site controller between 8 A and 30 A (between 1.7 kW and
7.2 kW) Built-in protection against overvoltage conditions and leakage current to ground
Operating temperature range: -40 °F to 122 °F (-40 °C to 50 °C)
4X enclosure type requirements, suitable for outdoor use.
•Shipping weight: Approximately 33lbs (14.97 kg)
Security standard compliance:
• CSA C22.2 No. 0-10 General Requirements – Canadian Electrical code, part II
• CSA 281.1-12/UL2231-1 Standard for safety for personnel protection systems for electrical vehicle
(EV) supply circuits: General requirements
• CSA 281.2-12/UL2231-2 Standard for safety for personnel protection systems for electric vehicle
(EV) supply circuits: Particular requirements for protection devices for use in charging systems
• CSA C22.2 No. 280-13/UL2594 (1
st
edition) Electric vehicle supply equipment (EVSE)
• Supported communication protocols: ONP and OCPP (CoRe+V2 and CoRe+PSV2 only)
• This product is approved by the California Type Evaluation Program
•The following models are certified ENERGY STAR® 1.2: CoRe+V2 and CoRe+PSV2 only
254081
Models: CoRe+V2,
CoRe+VBV2, CoRe+PSV2
Company Info: FLO (AddEnergie Technologies Inc.)
