Flo CoRe+ Series - Closing the Housing of the Station; Final Assembly Steps

CoRe+
TM
Installation Guide
11
Closing the Housing
of the Station
• Connect the cables to
their connectors.
• Install the head to the base, making
sure that the seals stay in place, then
install the four mounting screws.
• Install a o-ring to the upper screw.
• Ground
• Data
cable
Output
• O-ring
