Assembly of Step 2
NOTE
CARRIDGE BOLT
HEADS MUST FACE
INSIDE OF LIFT.
NUTS MUST FACE
OUTSIDE OF LIFT.
NOTE
WATER DEPTH
STICKERS MUST FACE
OUT ON FRONT AND
REAR OF LIFT.
110-00000-00 (x4)
SAND PAD WELDMENT
