Floe VSD 5000 - Assembly Image Definitions

continued
Step
Part Numbers
QTY Descriptions Torques
001-70211-00
001-76072-00
001-70227-00
002-04140-00
007-06201-00
4
5
1
1
1
HHCS, 1/2-13 x 2” ss 18-8
NUT, 1/2-13 ALUMINUM NYLOCK
HHCS, 1/2-13 x 7” ss 18-8
HOLDER, CABLE
SHEAVE, 3” FRONT CABLE ½” ID
45 ft. lbs.
45 ft. lbs.
001-70109-00
001-71017-00
001-76071-00
001-70124-00
001-76071-00
4
8
4
4
4
HHCS, 3/8-16 x 1 1/2” ss 18-8
3/8” SAE FLAT WASHER
NUT, 3/8-16 ALUMINUM NYLOCK
HHCS, 3/8-16 x 5 1/2” ss 18-8
NUT, 3/8-16 ALUMINUM NYLOCK
10 ft. lbs.
35 ft. lbs.
Assembly Image Definitions
Tighten without Clamping
Centerline
Hardware Card # Check, Inspect, Verify
Important Notice
