Floe VSD 5000 - Hardware Card Contents

Card Contents (511-04255-00)
Step
Part Numbers
QTY Descriptions Torques
001-70215-00
001-70217-00
001-70210-00
001-70219-00
001-71023-00
001-76072-00
6
8
8
2
48
24
HHCS, 1/2-13 x 3” ss 18-8
HHCS, 1/2-13 x 3 1/2” ss 18-8
HHCS, 1/2-13 x 1 3/4” ss 18-8
HHCS, 1/2-13 x 4” ss 18-8
FLAT WASHER, .5 ID x .75 OD ss
NUT, 1/2-13 ALUMINUM NYLOCK
60 ft. lbs.
45 ft. lbs.
45 ft. lbs.
60 ft. lbs.
001-70218-00
001-76072-00
4
4
HHCS, 1/2-13 x 3 3/4” ss 18-8
NUT, 1/2-13 ALUMINUM NYLOCK
20 ft. lbs.
001-76071-00
001-70115-00
001-70117-00
8
4
4
NUT, 3/8-16 ALUMINUM NYLOCK
HHCS, 3/8-16 x 3” ss 18-8
HHCS, 3/8-16 x 3 1/2” ss 18-8
35 ft. lbs.
001-70124-00
001-70127-00
001-76071-00
001-70121-00
2
1
6
3
HHCS, 3/8-16 x 5 1/2” ss 18-8
HHCS, 3/8-16 x 7” ss 18-8
NUT, 3/8-16 ALUMINUM NYLOCK
HHCS, 3/8-16 x 4 1/2” ss 18-8
35 ft. lbs.
35 ft. lbs.
35 ft. lbs.
001-70209-00
001-70245-00
001-76350-00
8
1
8
HHCS, 1/2-13 x 1 1/2” ss 18-8
HHCS, 1/2-20 x 1 3/4” ss 18-8
NUT, 1/2-13 ALUMINUM
45 ft. lbs.
50 ft. lbs.
