NO. PART NUMBER DESCRIPTION QTY
98* 111-00411-01 Ass'y, Canopy/Winch Insert 1
15 001-70207-00 HHCS, 1/2-13 x 1 1/4" 18-8 ss 1
31 001-71021-00 FLAT WASHER, 1/2" 18-8 SS 1
38 001-76072-00 NUT, NYLOCK 1/2-13 ALUM. 1
68 006-15022-00 Cap, Vinyl-Canopy/Winch Insert 1
107 911-14201-00 Canopy/Winch Insert, 38" 1
NO. PART NUMBER DESCRIPTION QTY
99* 111-00412-02 Ass'y, Ball Screw Tube-144.375" 1
1 001-16369-00 HHCS,3/4-16 x 4" Grade 5 Plain 1
2 001-23877-00 SHCS, 1/2-20 x 1 1/2" (Black) 1
5 001-33092-00 Flat Washer, SAE 3/4" Zinc 1
6 001-40365-00 Flat Washer, M24 Zinc 1
11 001-70123-00 HHCS, 3/8-16 x 5" 18-8 ss 1
14 001-70203-00 HHCS, 1/2-13 x 3/4" 18-8 ss 2
19 001-70215-00 HHCS, 1/2-13 x 3" 18-8 ss 2
31 001-71021-00 FLAT WASHER, 1/2" 18-8 SS 2
34 001-73454-00 SHCS, 10-32 x 1 3/4" 18-8 ss 1
37 001-76071-00 NUT, NYLOCK 3/8-16 ALUM. 1
38 001-76072-00 NUT, NYLOCK 1/2-13 ALUM. 2
39 001-76073-00 Nut, Nylock 10-32 Alum 1
41 001-93524-00 Nut, Slotted M24 x 1.5 1
64 006-10021-00 Sleeve, UHMW Ball Screw Support 1
70 006-22202-00 Sleeve, Steel 1" x 2.25" Lg. 1
72 007-05013-00 Plate, End Stop (Ball Screw) 1
75 007-05126-00 Fitting, Grease M8 x 1 (Flush) 2
76 007-05223-00 Coupler, Rigid .75x1.5x2 Lg. 1
77 007-05242-00 Key, 3/16" x 2" 1
83 007-09149-00 Cable, Lifting - 150.75" 1
86 011-15005-00 Ball Screw, 40-10mm - 1727mm 1
93 111-00248-00 Ass'y, Ball Nut Block 1
94 111-00311-00 Ass'y, Bearing Block w/bearing 1
97 111-00410-02 Weld't, Ball Screw Tube-144.375" 1
106 111-38500-00 Ass'y, Limit Switch 3800/5000 1
