Flomec TM Series User Manual

5
SPECIFICATIONS
Mechanical
Housing material: Nylon 6/6
Strain relief:
Hubble PG7. Grip range
(Cable Outside Diameter)
0.11 - 0.26 in. (2.8 – 6.6 mm)
Housing port thread: Female 1/2-20 UNF-2B (Compatible with PG7)
Cable
Belden 9363 (22 AWG
-
3 conductor
with drain wire and shield)
Cable length 10 ft. (3m), provided
Operating Temperature 0° to +140°F (-18° to +60°C)
Higher Process Fluid
Temperatures
Obtainable with G2
Stainless Steel Meters
When
i
nstalled on G2
S
tainless Steel Flowmeters,
s
ee
Ambient and Fluid Temperature Limits graph on next page
for higher process fluid temperature Limits.
If wider process fluid temperature ranges are desired,
reference information on FLOMEC® Remote Kits.
Storage temperature: -40° to +180°F (-40° to +82°C)
Power:
Type: Loop powered
Voltage minimum: 8 VDC
Voltage maximum: 32 VDC
Isolated: No
Primary Output (4-20mA):
Type: Loop
Minimum: 4 mA
Maximum: 25 mA
Scaled Pulse Output:
Type: Open Collector (NPN), Current Sinking
External Pull Up
Voltage
1
8.0 to 26 VDC
Internal Pull Up Voltage
2
5.0 VDC
1
NOTE: Customer supplied external voltage with separate power supply and a minimum
external pull up resistance of 820 ohms.
2
NOTE: 5VDC supplied internal on the 4-20mA board, no external supply or pull up
resistor required. Internal pull up is fixed at 100K ohm
