SPECIFICATIONS (Continued)
Dimensions
Length
(A)
Height
(B)
Width
(C)
Strain
Relief
(D)
4-20mA Module
3.45 in.
(88 mm)
0.90 in.
(23 mm)
2.18 in.
(55 mm)
0.86 in.
(22 mm)
Module shown installed on G2 1” stainless steel flowmeter
Figure 1
Note: This 4-20mA module is designed for use with most* FLOMEC meters that are equipped
with the Q9 display option. The 4-20mA module can be field calibrated through the
configuration menu options on the Q9 display.
*FLOMEC QSE meters have their own 4-20mA module.
