INSTALLATION, OPERATION, &
MAINTENANCE MANUAL
TITLE: F7000 / 8000 Series Rev. V
Pilot-Operated Safety Relief Valve Page 4 of 41
2.0 DESCRIPTION, OPERATION, SERVICE ENVELOPE, INSTALLATION, and STARTUP
Conventional / Tubed Pilot:
CLOSED OPEN
Integral Module (IM) Construction (legacy):
DOME
CAVITY
PICKUP
TUBE
INLET
OUTLET
PILOT VALVE
PISTON
ASSEMBLY
BODY
