IPS Detect
Page 22 of 35
OIM_FLS_IPS Detect_EN_14
Subject to technical changes! FLOWSERVE
8 Technical data
Ex- Characteristic (optional)
- Ex-marking II 2G Ex ia IIC T4 Gb
TÜV 07 ATEX 553845
IECEx Ex ia IIC T4 Gb
TUN 15.0038
If the sensor IPS Detect is to be installed in an explosion hazardous (Ex) area or other applications were
approvals are necessary, then respective official documentation must be observed. As standard, the unit can
be supplied with the following documentation: Operating Instruction, EC-Type Examination, Safety
Instruction and Declaration of Conformity)
Electrical Data
- output signal 4..20 mA with modulated FSK signal (physically Bell
202 HART
®
compatible)
only 8..20 mA support
IPS Detect:
10..20 mA vibration velocity
9 mA condition monitoring
- display sensor failure 21 mA (>20,5 mA)
- max. signal deviation 1,5 %
- min. current consumption 8 mA (4..8 mA are not supported)
- max. current consuption 22 mA
- min. required voltage at sensor input 11 V
- max. allowed load impedance
- connecting wire 2-wire
- connection 4-20 mA Internal screw-clamping terminal
Environmental Condition
- Safety class at EN 60529 IP66
- Allowed ambient temperature T
a
= -40 °C ... 80 °C
Mechanical Condition
- Dimension 76 x 40 x 53 mm
- Weight 0,12 kg
- Mounting of sensor M8 screw
- Material of body PA 6 GF 10 + GB 20, 22% Irgastadt P18, 3%
( )
