9
Logix 3200IQ Digital Positioner FCD LGENTB0058-03 – 01/11
flowserve.com
How to Order
Selection Code
Example
3
3
Protocol HART 2
2
Diagnostics
Standard 0
1
Advanced 1
Material
Aluminum, White Paint (Valtek) 0
0
Stainless Steel, No Paint (Valtek) 1
Aluminum, Black Paint (Automax) 2
Aluminum, Food-Grade White Paint (Automax) 3
Aluminum, Black Paint (Accord) 4
Aluminum, Food-Grade White Paint (Accord) 5
Design Version IQ
IQ
Certifications
Explosionproof EEx d IIB + H
2
, ATEX II 2 G (CENELEC) 07
10
Explosionproof Class I, Div 1, Groups B, C, D Intrinsically Safe Class I,
Div 1, Groups A through G (FM, CSA) FM Nonincendive. CSA Class I,
Div 2, Class I, Zone 1, Group IIB + H
2
and Exia Class 1, Zone 0,
Group IIC (CSA Only)
10
General Purpose 14
Intrinsically Safe EEx ia IIC T4, Standard Temp: -40°F (-40°C) ≤ Ta ≤ 176°F (80°C)/131°F (55°C), ATEX
II 1 G (CENELEC)
15
IECEx Ex d IIB + H
2
16
Shaft
DD 316 Stainless Steel Shaft (Valtek Standard) D6
D6
NAMUR 316 Stainless Steel (VDI/VDE 3845) N6
Conduit
Connections
½" NPT E
E
M20 M
Action
Four-way (Double-Acting) 04
04
Three-way (Single-Acting) 03
Four-way Vented (Double-Acting) 4V
Three-way Vented (Single-Acting) 3V
Temperature Operating Temperature (-40°F to 176°F; -40°C to 80°C) 40
40
Gauges
Gauges (Valtek standard) OG
OG
Stainless Steel Gauges OS
Stainless Steel with Brass Internals (kg/cm
2
) KG
Stainless Steel with Stainless Steel Internals (kg/cm
2
) KS
No Gauges OU
Special Options
4-20 mA Position Feedback OF
OF
No Specials OO
