Flowserve Logix 3800zb User Manual

Logix™ 3800zb Digital Positioner FCD AIIOM001030_EN 02/23
flowserve.com 45
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
A
B
C
D
E
F
G
Menu Feature
Description
Menu Location
Stroke/Quick Calibration
Stroke/Quick Calibration starts an automatic calibration of the
position feedback sensor. The stroke calibration determines the
closed (0%) and open (100%) positions of the valve and gathers
information about the response of the valve (such as valve stroke
time) to determine the gains. The gains automatically are then set.
After a stroke calibration, the positioner is ready to control.
5.1
Command Input
Calibration
Command Input Calibration is used to adjust the input range. Set the
lowest current (Set 0%) and the highest current used (Set 100%).
The default input range is 4 to 20 mA. The “Set 0%” value must be
lower than the “Set 100% value.
5.2
Calibration Dates
Calibration Dates lists the most recent date of each calibration.
5.3
Back
5.4
Configuration
Positioner Tuning
6.1
