Logix™ 3800zb Digital Positioner FCD AIIOM001030_EN 02/23
flowserve.com 48
Menu Feature
Description
Menu Location
Set 0%
Set the current (mA) that will correspond to the 0% (closed) valve
position.
7.1.1
Set 100%
Set the current (mA) that will correspond to the 100% (open) valve
position.
7.1.2
Back
7.1.3
AI
7.2
Set 0%
Set the current (mA) that will correspond to the 0% (closed) valve
position.
7.2.1
Set 100%
Set the current (mA) that will correspond to the 100% (open) valve
position.
7.2.2
Back
7.2.3
DI
7.3
No Function
No Action
7.3.1
Start PST
Trigger to start a PST
7.3.2
Cmd Override
Trigger to start a Cmd Overide
7.3.3
Set Cmd Point
Change Set Cmd Point variable.
7.3.4
Back
7.3.5
Language
8
English
8.1
German
8.2
French
8.3
Spanish
8.4
Portuguese
8.5
Russian
8.6
Italian
8.7
Back
8.8
Display
9
Contrast
LCD Contrast. Customer's Choice
9.1
Backlight
LCD Backlight. Customer's Choice
9.2
LCD Orientation
(Standard, Rotate 180˚)
9.3
Back
9.4
