Place the gasket and electronic assembly onto the meter assembly.
Reinstall the 8 screws (PH-13) to secure the electronic assembly to the
meter assembly. Tighten the screws to 32-36 inch-pounds in a star pattern
to avoid any leakage.
5.2 Meter Chamber Removal
Exposure to chemicals can cause bodily harm. Before
disassembling, thoroughly ush the meter with water. Always
wear appropriate gloves, eye protection and any other necessary
PPE while working with chemicals.
Ensure that the meter is not under pressure before continuing.
Remove the 8 screws (PH-13) to remove electronic assembly (S10-11B
COMPLETE). Remove the 4 screws (PH-03) that secure the meter plate
(S10-02N) to the uid housing (S10-05N). Remove the meter plate and
O-ring (S10-03). The meter chamber can now be removed for cleaning or
replacement.
5.3 Meter assembly procedure
Ensure that the bottom O-ring (S10-04) is in place. Insert the meter
chamber into the uid housing (S10-05N). Place O-ring (S10-03) around the
bottom of the meter plate (S10-02N) and place on top of the uid housing
(S10-05N). Secure with 4 short screws (PH-03) torqued to 32-36 inch-
pounds. After inspecting for damage, install the gasket (S10-12) and the
electronic assembly (S10-11B COMPLETE) using the 8 long screws (PH-13)
torqued to 32-36 inch-pounds.
