6. Parts List and Parts Diagram
Polypropylene/Nylon SEM-100/SEM-100FT Parts List
Qty. Part No. Description
8 PH-13 SS Screw, Long
1 S10-11B COMPLETE Electronic Assembly
1 S10-02 Meter Gasket
4 PH-03 SS. Screw, Short
1 S10-02 Meter Plate
1 SEM-100 KIT-2
Metering Chamber Kit:
S10-03 or S10-07
S10-04 or S10-08
SFM10000-01
SFM10000-02
SFM10000-03-0A
S10-14
(1) S10-05 SEM-100 Polypropylene Fluid Housing
(1) S10-05N SEM-100 Nylon Fluid Housing
(1) S10-10 SEM-100FT Nylon Fluid Housing
(1) S10-10P SEM-100FT Polypropylene Fluid Housing
Note: All parts are common to the SEM-100 and SEM-100FT except for the fluid housing
