Fluidwell E018 Operation Manual

Page 17
FW-E115-P-M_v0203_03_EN.docx
1.3
K-FACTOR A
With the Total K-Factor, the flowmeter pulse signals from pickup A are
converted to a total unit. The Total K-Factor is based on the number
of pulses generated by the flowmeter per selected measurement unit
(SETUP 1.1).. The more accurate the Total K-Factor, the more
accurate the functioning of the system will be.
After pressing PROG, the decimal point will be flashing. The decimal
position can be changed now by pressing the ▲-key.
1.4
FACTOR-X
This setting determines the multiplication factor of Total and
Accumulated Total and is also applicable to the Current and Previous
Day Totals. This functions it possible to show up to 3 digits more of
the Total/accumulated Total. The amount shown is a rounded
number. The following can be selected:
x1 – x10 – x100 – x1000
1.5
CLEAR PASSWORD
Clearing Total by the Operator can be password protected.
This protection is disabled with value 000 (zero).
A 3 digit password can be programmed, for example 123.
1.6
CONTRACT HOUR
The contract hour can be set in steps of 1 hour to any hour of the day.
When the system clock reaches the time set in the contract hour, the
Current Day Total is copied to the Previous Day Total, after which the
measurement of the Current Day Total is restarted (reset to zero).
Clock – the clock will be interrupted in case of a power-down. When
the unit is powered up again, the display will immediately ask the
operator to enter the correct system time.
Without an initialized clock, all measurements and calculations are
performed as normal. However, when the Daily Total feature is
enabled, the detection of contract hour and updating the Current and
Previous Day Totals will not be done at the correct time.
1.7
CURRENT DAY-TOTAL
This setting shows the amount of product totalized, since the last
contract hour. This a ‘running’ totalizer and cannot be reset to zero.
1.8
PREVIOUS DAY-TOTAL
This setting shows the amount of product totalized, before the last
contract hour. This totalizer cannot be reset to zero.
See chapter 2 for information on reviewing more historical day totals.
3.3.3 EXPLANATION OF SETUP-MENU 2 – FLOWRATE A
• First setup the flowmeter at SETUP-menu 6 - Flowmeter. It has a direct influence on the
settings for Flowrate.
• Change of the type of flowmeter unit (SETUP 6.6 and SETUP 6.7) will cause the flowrate
unit to jump to the default setting of the new flowmeter unit type.
• Changes to SETUP 2.1 Unit, SETUP 2.2 Time unit and SETUP 2.3 Decimals have an
effect on the analog output settings of SETUP 7.2 Rate Min and SETUP 7.3 Rate Max
and the display setting of SETUP 5.6 Ratespan.
Therefore it is best practice to first determine the required settings for the flowrate!
2
FLOWRATE
2.1
UNIT
This setting determines the measurement unit for flowrate. The
flowrate unit that can be chosen depends on the type of flowmeter
unit (volumetric or mass) set at SETUP 6.6.
The following can be selected:
AUTO-VOL: mL - L - m3 - US GAL - I GAL - cf - Oil bbl - nL - nm3 -
scf
AUTO-MAS: mg - g - kg - ton - lb - US ton
Hand: mL - L - m3 - US GAL - I GAL - cf - Oil bbl - nL - nm3 -
scf - mg - g - kg - ton - lb - US ton - rev - P - ---- (no
unit)
2.2
TIME
The flowrate can be calculated per /sec - /min - /hour - /day.
