Fluidwell E018 Operation Manual

Page 56
FW-E115-P-M_v0203_03_EN.docx
Runtime variables of the E115-P – Floating point based 32 bit
PDU
ADDRESS
HOLDING
REGISTER
VARIABLE
NO.
REGISTERS
R/W
TYPE
VALUE / REMARKS
[d] 6400
[h] 0x1900
46401
error status (bitfield)
1
R
uint16
See list at register 516 in ‘individual read’ section.
[d] 6401
[h] 0x1901
46402
reserved
1
R
uint16
Reserved for future use
[d] 6402
[h] 0x1902
46403
grand total
(differential)
2
R
float32
0…9999999
Representation: unit depending on variable 32
[d] 6404
[h] 0x1904
46405
grand accumulated
total (differential)
2
R
float32
0…99999999999
Representation: unit depending on variable 32
[d] 6406
[h] 0x1906
46407
grand flow rate
(differential)
2
R
float32
0…9999999
Representation: unit and time depending on
variables 48, 49
[d] 6408
[h] 0x1908
46409
current day grand
total
2
R
float32
0…99999999999
Representation: unit depending on variable 32
[d] 6410
[h] 0x190A
46411
previous day grand
total
2
R
float32
0…99999999999
Representation: unit depending on variable 32
[d] 6416
[h] 0x1910
46417
total A
(forward)
2
R
float32
0…9999999
Representation: unit depending on variable 32
[d] 6418
[h] 0x1912
46419
accumulated total A
(forward)
2
R
float32
0…99999999999
Representation: unit depending on variable 32
[d] 6420
[h] 0x1914
46421
flow rate A
(forward)
2
R
float32
0…9999999
Representation: unit and time depending on
variables 48, 49
[d] 6422
[h] 0x1916
46423
total B
(reverse)
2
R
float32
0…9999999
Representation: unit depending on variable 32
[d] 6424
[h] 0x1918
46425
accumulated total B
(reverse)
2
R
float32
0…99999999999
Representation: unit depending on variable 32
[d] 6426
[h] 0x191A
46427
flow rate B
(reverse)
2
R
float32
0…9999999
Representation: unit and time depending on
variables 48, 49
Note: The list of runtime variables shown above can be read as one contiguous list of registers. Unused registers return 0.
Runtime variables of the E115-P – Floating point based 64 bit
PDU
ADDRESS
HOLDING
REGISTER
VARIABLE
NO.
REGISTERS
R/W
TYPE
VALUE / REMARKS
[d] 6656
[h] 0x1A00
46657
grand total
(differential)
4
R
float64
0…9999999
Representation: unit depending on variable 32
[d] 6660
[h] 0x1A04
46661
accumulated total
(differential)
4
R
float64
0…99999999999
Representation: unit depending on variable 32
[d] 6664
[h] 0x1A08
46665
current day grand
total
4
R
float64
0…99999999999
Representation: unit depending on variable 32
[d] 6668
[h] 0x1A0C
46669
previous day grand
total
4
R
float64
0…99999999999
Representation: unit depending on variable 32
[d] 6672
[h] 0x1A10
46673
total A
(forward)
4
R
float64
0…9999999
Representation: unit depending on variable 32
[d] 6676
[h] 0x1A14
46677
accumulated total A
(forward)
4
R
float64
0…99999999999
Representation: unit depending on variable 32
[d] 6680
[h] 0x1A18
46681
total B
(reverse)
4
R
float64
0…9999999
Representation: unit depending on variable 32
[d] 6684
[h] 0x1A1C
46685
accumulated total B
(reverse)
4
R
float64
0…99999999999
Representation: unit depending on variable 32
Note: The list of runtime variables shown above can be read as one contiguous list of registers. Unused registers return 0.
