Fluidwell E018 Operation Manual

Page 57
FW-E115-P-M_v0203_03_EN.docx
Configuration variables of the E115-P
Total - A
PDU
ADDRESS
HOLDING
REGISTER
VARIABLE
NO.
REGISTERS
R/W
TYPE
VALUE / REMARKS
[d] 32
[h] 0x020
40033
unit
1
R/W
uint16
0=none
1=L
2= m
3
3=US GAL
4= I GAL
5=CF
6= OilBBL
7=kg
8=ton
9=lb
10=us ton
[d] 33
[h] 0x021
40034
decimals
1
R/W
uint16
0…3
[d] 34
[h] 0x022
40035
K-factor - A
2
R/W
uint32
1...9999999
Representation: 0.000010…9999999 depending on
variable 37: decimals K-factor.
[d] 37
[h] 0x025
40038
K-factor
decimals - A
1
R/W
uint16
0…6
[d] 47
[h] 0x02F
40048
Multiply
factor
1
R/W
uint16
0=x1
1=x10
2=x100
3=x1000
[d] 1052
[h] 0x41C
41053
clear total
password
1
R/W
unit16
000 … 999
Setting 000 disables the clear total password feature.
[d] 2146
[h] 0x862
42147
Contract
hour
1
R/W
uint16
0…23 Hour
Flowrate - A
PDU
ADDRESS
HOLDING
REGISTER
VARIABLE
NO.
REGISTERS
R/W
TYPE
VALUE / REMARKS
[d] 48
[h] 0x030
40049
unit
1
R/W
uint16
0=none
1=mL
2=L
3=m
3
4=US GAL
5=I GAL
6=CF
7=OilBBL
8=nL
9=nm
3
10=SCF
11=mg
12=g
13=kg
14=ton
15=lb
16=US
17=rev
18=P
[d] 49
[h] 0x031
40050
time unit
1
R/W
uint16
0=/sec
1=/min
2=/hour
3=/day
[d] 50
[h] 0x032
40051
decimals
1
R/W
uint16
0…3
[d] 51
[h] 0x033
40052
K-factor – A
2
R/W
uint32
1...9999999
Representation: 0.000010…9999999
depending on variable 54: decimals K-factor.
[d] 54
[h] 0x036
40055
K-factor
decimals - A
1
R/W
uint16
0…6
[d] 55
[h] 0x037
40056
number of
pulses
1
R/W
uint16
1...255
[d] 56
[h] 0x038
40057
cut-off time
1
R/W
uint16
1...9999
Representation: 0.0001 – 9.999 sec
Total – B
PDU
ADDRESS
HOLDING
REGISTER
VARIABLE
NO.
REGISTERS
R/W
TYPE
VALUE / REMARKS
[d] 40
[h] 0x028
40041
K-factor – B
2
R/W
uint32
1...9999999
Representation: 0.000010…9999999 depending on
variable 37: decimals K-factor.
[d] 43
[h] 0x02B
40044
K-factor
decimals – B
1
R/W
uint16
0…6
Flowrate – B
PDU
ADDRESS
HOLDING
REGISTER
VARIABLE
NO.
REGISTERS
R/W
TYPE
VALUE / REMARKS
[d] 227
[h] 0x0E3
40228
K-factor – B
2
R/W
uint32
1...9999999
Representation: 0.000010…9999999
depending on variable 54: decimals K-factor.
[d] 230
[h] 0x0E6
40231
K-factor
decimals – B
1
R/W
uint16
0…6
Display
PDU
ADDRESS
HOLDING
REGISTER
VARIABLE
NO.
REGISTERS
R/W
TYPE
VALUE / REMARKS
[d] 64
[h] 0x040
40065
display
function
1
R/W
uint16
0=total
1=flowrate
2=acc.total
[d] 65
[h] 0x041
40066
SHOW A-B
1
R/W
uint16
0=disable
1=enable
