Fluke 1503 Datasheet

4 Fluke Corporation 1507/1503 Insulation Testers
EN61557 Specifications cont.
Insulation resistance maximum and minimum displa
y values
cont.
50 V 100 V 250 V 500 V 1000 V
Minimum Minimum Minimum Minimum Minimum
Limit Value Display Limit Value Display Limit Value Display Limit Value Display Limit Value Display
Value Value Value Value Value
7.0 9.10 7.0 9.10 7.0 9.10 7.0 9.10 7.0 9.1
8.0 10.40 8.0 10.40 8.0 10.40 8.0 10.40 8.0 10.4
9.0 11.70 9.0 11.70 9.0 11.70 9.0 11.70 9.0 11.7
10.0 13.0 10.0 13.0 10.0 13.0 10.0 13.0 10.0 13.0
20.0 26.0 20.0 26.0 20.0 26.0 20.0 26.0 20.0 26.0
30.0 39.0 30.0 39.0 30.0 39.0 30.0 39.0 30.0 39.0
40.0 52.0 40.0 52.0 40.0 52.0 40.0 52.0 40.0 53.0
50.0 65.0 50.0 65.0 50.0 65.0 50.0 65.0
60.0 78.0 60.0 78.0 60.0 78.0 60.0 78.0
70.0 91.0 70.0 91.0 70.0 91.0 70.0 91.0
80.0 104.0 80.0 104.0 80.0 104.0 80.0 104.0
90.0 117.0 90.0 117.0 90.0 117.0 90.0 117.0
100.0 130.0 100.0 130.0 100.0 130.0
200.0 260.0 200.0 260.0
300.0 390.0 300.0 390.0
400.0 520.0 400.0 520.0
500.0 650.0
600.0 780.0
700.0 910.0
800.0 1040.0
900.0 1170.0
1000.0 1300.0
2000.0 2600.0
Earth bond resistance maximum display values
Limit Value Maximum Display Value
0.4 0.28
0.5 0.35
0.6 0.42
0.7 0.49
0.8
0.56
0.9 0.63
1.0 0.7
2.0
1
.4
3.0 2.1
4.0 2.8
5.0 3.5
6.0 4.2
7.0 4.9
8.0
5.6
9.0 6.3
10.0 7.0
20.0
1
4.0
30.0 21.0
40.0
28.0
50.0 35.0
60.0 42.0
70.0 49.0
8
0.0
56.0
90.0 63.0
Limit Value Maximum Display Value
100.0 70.0
200.0 140.0
300.0 210.0
400.0 280.0
500.0 350.0
600.0 420.0
7
00.0
49
0.0
800.0 560.0
900.0 630.0
1
000.0
700.0
2000.0 1400.0

Fluke 1503 Specifications

General

Display type	-
Housing color	Grey, Yellow
Maximum voltage	600 V
Drop proof up to	1 m
Operating altitude	0 - 2000 m
Auto discharge time	0.5 s
Operating vibration	2 G
Overload protection	Yes
Non-operating altitude	0 - 12000 m
Maximum capacitive load	1 µF
Storage temperature (T-T)	-40 - 60 °C
Operating temperature (T-T)	-20 - 55 °C
Insulation measurement range	0.01 - 2000 MΩ
Insulation test voltage accuracy	20 %
Operating relative humidity (H-H)	0 - 95 %
Insulation measure accuracy (500V)	1.5 %
International Protection (IP) code	IP40
Battery size	AA
Number of batteries supported	4

Weight and Dimensions

Depth	50 mm
Width	100 mm
Height	203 mm
Weight	550 g
