Fluke 1625 User Manual

1625
Users Manual
2
Notes
• The terms earth and earthing also refer to ground and grounding
and is used interchangeably throughout this manual.
• For stakeless earth resistance measurements, the EI-1625 must
be purchased. (The EI-1625 comes standard with the 1625 Kit).
Refer to Appendix A for a complete set of operating information
including specifications.
• Selective measurements are described in the main section of this
manual.
Figure 1 displays the Fluke 1625 Earth/Ground Tester:
R
RA
R
Earth/Ground Resistance 300k
AC
Resistance
300k
DC Low Resistance 3 k
CHANGE
ITEM
SELECT
START
TEST
DISPLAY
MENU
H/C2
S/P2
ES/P1
E/C1
4 POLE
3 POLE
4 POLE
2 POLE
2 POLE
4 POLE
OFF
3 POLE
EARTH / GROUND TESTER
1625
ST
edw001.eps
Figure 1. Fluke 1625 Earth/Ground Tester

Fluke 1625 Specifications

General

Storage Temperature	-20 °C to 60 °C
Testing Methods	3-pole fall-of-potential, 4-pole
Measurement Frequency	128 Hz
Power Supply	6 x 1.5 V AA batteries or optional AC adapter
Safety Rating	CAT II 300 V
Safety Standards	IEC 61010-1
