1625
Users Manual
22
D "CHANGE ITEM" button to change the set point entry values.
E "SELECT" button to select the digit to be changed.
F Display unit, liquid crystal digits, 18 mm high with automatic decimal
point as well as active illumination.
G Connecting socket H (auxiliary earth electrode) (4 mm ø) also usable
with safety measuring lead
H Connecting socket G (probe) (4 mm ø) also usable with safety measuring
lead.
I Connecting socket for an ext. clip-on current transformer (optional).
W Warning
No voltage permissable to sockets EFGH.
J Connecting socket F (earthing probe) (4 mm ø) also usable with safety
measuring lead. Potential pick off with 4-pole earthing measurement.
K Connecting socket E (earth electrode) (4 mm ø) also usable with safety
measuring lead.
W Attention
Do not open or close the instrument with force!
L Battery compartment for: 6 x IEC LR6 batteries or type AA batteries.
W Warning
Disconnect all leads before opening the instrument!
M Screws to fasten the battery compartment
