Fluke 1750 Technical Data

6 Fluke Corporation Fluke 1750 Three-Phase Power Recorder
Specifications for the System:
Recorder and Power Analyze Software
General
Power quality measurement standards
Conformance
IEC 61999-1-4 Class 1, IEC 61000-4-30, IEEE519, IEEE1159, IEEE1459 and EN50160
Clock/calendar
Leap years, 24-hour clock
Real-time clock accuracy
Not more than ± 1 s/day
Internal memory capacity for data
At least 2 GB
Maximum recording period
At least 31 days
Measurement time control
Automatic
Maximum number of events
Limited only by the size of the internal memory
Power requirements
100 to 240 V rms ± 10 %, 47-63 Hz, 40 W
Operating time during interruptions
(internal UPS operation)
5 minutes per interruption, 60 minutes total operating time without recharging
Dimensions
215 mm x 310 mm x 35 mm (8.5 in x 12.2 in x 3.5 in)
Mass (weight)
6.3 kg (14 lb)
Input
Measurement types
One Phase Plus Neutral, One Phase IT No Neutral, One Phase Split Phase, Three Phase Wye,
Three Phase Delta, Three Phase IT, Three Phase High Leg, Three Phase Open Leg, 2 Element Delta,
2
1
/
2
Element Wye
Input channels
Voltage: 4 channels, ac/dc
Current: 5 channels
Voltage channels
Input resistance: 2 MΩ
Input capacitance: < 20 pF
Current input characteristics
2 V rms = full scale, 1 MΩ Input Impedance for ferro CTs, low impedance for Flexi-CTs
Measuring method
Simultaneous digital sampling of voltage and current. Digital PLL synchronized sampling, internal
frequency reference used during voltage drops.
Synchronization and sampling
PLL-synchronization source
The PLL synchronizes to the A-N voltage for wye power types, and to the A-B voltage for delta
power types. All listed power types can be characterized as either wye or delta.
PLL lock range
42.5 to 69 Hz
Sampling frequency
Voltage and current: 256 samples/cycle
Inter-harmonics per IEC 61000-4-7: 2560 points/10 cycles (50 Hz),
3072 points/12 cycles (60 Hz)
Transient Voltage: 5 MHz
A/D resolution
Voltage and current: 24 bits
Transient voltage: 14 bits
Voltage and current measurements
Voltage measurement range
AC voltage: 1000 V rms ± 10 % over range
DC voltage: ± 1000 V + 10 % over range
Voltage crest factor
3 or less
Current measurement range
Depends on current probe used
Current crest factor
4 or less
Voltage and current measurement accuracy
RMS voltage
Measurement type
True rms calculated continuously: every cycle, every 1/2 cycle, and
every 10 or 12 cycles at 50 or 60 Hz respectively, as required by IEC 61000-4-30.
Measurement uncertainty
AC: ± 0.2 % reading ± 0.1 % full scale, above 50 V rms
DC: ± 0.5 % reading ± 0.2 % full scale, above 50 V dc
RMS current
Measurement type
True rms calculated continuously: every cycle, every 1/2 cycle, and
every 10 or 12 cycles at 50 or 60 Hz respectively, as required by standards
Measurement uncertainty
Ferromagnetic Clamps: ± (0.1 % full scale + 0.2 % reading + current sensor accuracy),
valid for 5 % to 100 % of current sensor range
Flexible Current Probes: ± (0.1 % full scale + 0.5 % reading + current sensor accuracy),
valid for 5 % to 100 % of current sensor range

Fluke 1750 Specifications

General

Brand	Fluke
Model	1750
Category	Data Loggers
Language	English
