287/289
Users Manual
44
Trigger Level
30% Above
Trigger
Level
100%
Trigger Level
70% Below
Trigger Level
100%
Measures Positive Pulse
Measures Negative Pulse
est28.eps
Figure 25. Duty Cycle Measurements
