Fluke 360 User Manual

AC Leakage Current Clamp Meter
Symbols
3
Symbols
Table 1 describes the symbols that appear on the Meter or in this document.
Table 1. Symbols
Symbol Explanation
T
Product is protected by double insulation
W
Risk of Danger. Important information.
X
Hazardous voltage. Risk of electrical shock.
B
AC (Alternating Current)
F
DC (Direct Current)
J
Earth ground
,
Application to or removal from hazardous, live conductors is permitted
~
Do not dispose of this product as unsorted municipal waste. Go to Fluke’s Web site
for recycling information.
P
Conforms to requirements of European Union
M
Battery
Specifications
General Specifications
Measurement functions........................................ AC current
Additional functions ............................................. Data hold and auto power off
Display (LCD)
Digital reading..................................................... 3200 counts
Bar graph ............................................................ 32 segments
“OL” over-range indication
Low-battery symbol
Range selection .................................................... Automatic
Sampling
Digital reading..................................................... 2 times per second
Bar graph ............................................................ 12 times per second
Operating temperature and humidity range ....... 0 °C to 50 °C (32 °F to 122 °F) with a maximum humidity of 80 % RH
(no condensation)
Storage temperature and humidity range........... -20 °C to 60 °C (-4 °F to 140 °F) with humidity range 20 to 70 % RH
(no condensation)
Temperature coefficient ...................................... ± 0.05 % of measuring range / °C (< 18 °C or > 28 °C)
Measuring range................................................. 0 to 50 A
Effect of external magnetic fields........................ 0.0005 % typical value (in terms of the magnitude of current in adjacent
wires)
Maximum conductor size ..................................... 40 mm (1.6 in)
Maximum circuit voltage ...................................... 300 V rms
Power consumption.............................................. 6 mW maximum
Automatic power off ............................................. Automatically turns off the power approximately 10 minutes after the
last switch operation. The beeper will turn on 15 seconds before power
off.
Power supply......................................................... CR2032 lithium battery
Battery life ............................................................. Approximately 90 hours of continuous operation
