Fluke 572 Getting Started

19
576
Model 576:
IMPORTANT! Before you install the software
you must connect the unit with the PC to
configure the USB interface.
Proceed as follows:
Connect the unit to the PC via USB. New Hard-
ware will be found. You have to install three dif-
ferent device drivers - two for USB ports and one
for the camera. A driver is software needed by
your PC to communicate with the thermometer
and the camera. You will be asked three times to
install a driver.
Note! During the driver installation, a message
window could appear, indicating that a particular
driver is not supported or authorized by Micro-
soft. Please ignore this message and continue
with the installation.
The Windows Hardware Assistant will guide you
through the installation process. If you are asked
where to look for the drivers choose CD-ROM. In
most cases, Windows will find the drivers auto-
matically. If Windows asks for the file STV680u.
dll please point to the driver‘s folder of the CD.
Now you can install the IRGraph software as
described for the Model 574.
After launching the software you will be asked for
the right COM port. This number can be found in
the Hardware manager of Windows.
The Hardware Manager is located in the “Control
Panel” of the Computer (On some versions of
Windows, it is found under System\Hardware).

Fluke 572 Specifications

Temperature

temperature range	-30 to 900°C (-25 to 1600°F)
ambient operating range	0 to 50°C (32 to 122°F)
storage temperature	-20 to 50°C (-4 to 122°F)

Display

display resolution	0.1°C (0.2°F)
accuracy at 25°C	± 0.75% of reading or ± 1K (± 1.5°F)
repeatability	±0.5% of reading or ±1°C (±2°F)

Power

power	2 x 1.5 V Alkaline Type AA
battery life	13 hrs. (50% laser and 50% backlight used)
response time (95%)	250 mSec

Dimensions

dimensions	200 x 170 x 50 mm (7.9 x 6.7 x 2 inches)
tripod mount	1/4”-20 UNC
optical resolution (standard focus)	60 : 1 (19mm spot size at 1.15M)
