Fluke 572 Getting Started

5
572/574/576
Table of Contents
Introduction ............................................................ 6
Warning for the Model 574 NI ................................ 7
Symbols and Safety Markings ............................... 8
Laser Warning and Serial Number Labels .............. 9
Features and Requirements ................................... 10
Delivery Content ..................................................... 11
Batteries ................................................................. 12
Measurement .......................................................... 13
Field of View and Emissivity ................................... 14
Spot Size ................................................................ 15
Additional Functions ............................................... 16
DIP Switches .......................................................... 17
Hardware and Software Setup ............................... 18
Using the Camera (Model 576) ............................... 20
Uploading Data and Pictures (Model 576) ............. 22
Troubleshooting ...................................................... 23
Maintenance ........................................................... 24
CE Confirmity ......................................................... 25
Specification of the Thermometers ........................ 26
Specification of the Camera (Model 576) ............... 27
Factory Defaults ..................................................... 28

Fluke 572 Specifications

Temperature

temperature range	-30 to 900°C (-25 to 1600°F)
ambient operating range	0 to 50°C (32 to 122°F)
storage temperature	-20 to 50°C (-4 to 122°F)

Display

display resolution	0.1°C (0.2°F)
accuracy at 25°C	± 0.75% of reading or ± 1K (± 1.5°F)
repeatability	±0.5% of reading or ±1°C (±2°F)

Power

power	2 x 1.5 V Alkaline Type AA
battery life	13 hrs. (50% laser and 50% backlight used)
response time (95%)	250 mSec

Dimensions

dimensions	200 x 170 x 50 mm (7.9 x 6.7 x 2 inches)
tripod mount	1/4”-20 UNC
optical resolution (standard focus)	60 : 1 (19mm spot size at 1.15M)
