Parts and Accessories
21
Parts and Accessories
Refer to Table 8 and Figure 10.
Table 8. Replacement Parts
Item Description Part/ Mod. No. Qty
AC70A Alligator clips AC70A 1
BT1, BT2 9 V battery, ANSI/NEDA 1604A or IEC 6LR61 614487 2
Holster Holster, Yellow 664182 1
WF1 Fuse, 125 mA, 250 V fast
W
To ensure safety, use exact replacement only. 686527 1
H2, 3, 4 Case screw 832246 3
H5, 6 Battery door fasteners 948609 2
H7, 8 Bracket screw 641131 2
MP1 LCD bezel, 718 30G 664158 1
MP1 LCD bezel, 718 100G 664169
MP2 LCD 686482 1
MP3, 4 Pump retainer bracket 664201 2
MP5 Gasket 664208 1
MP6 Pump assembly, 718 30G 691383 1
MP6 Pump assembly, 718 100G 691748 1
MP7, 8 Selector knob 664193 2
MP9 Vernier adjust knob 664190 1
MP10 Pump handle knob 664185 1
MP11, 12, 13 O-ring 146688 3
MP14 Spacer 687449 1
