Fluke 7341 - Specifications

Specifications and Environmental Conditions
Specifications 3
3-3
Specifications
Table 3-1describes the product specifications.
Table 3-1. Specifications
Item Description
Range –45°C to 150°C
Stability (2 sigma)
±0.005°C at –40°C (ethanol)
±0.005°C at 25°C (water)
±0.007°C at 150°C (5012 oil)
Uniformity
±0.007°C at –40°C (ethanol)
±0.007°C at 25°C (water)
±0.010°C at 150°C (5012 oil)
Heating Time*
120 minutes, from 25°C to 150°C (5012 oil @ 115V)
Cooling Time
130 minutes, from 25°C to –45°C (ethanol)
Stabilization Time
15-20 minutes
Temperature Setting
Digital display with push-button entry
Set-point Resolution
0.01°; 0.00018° in high resolution
Display Temperature
Resolution
0.01°
Digital Setting Accuracy
±1°C
Digital Setting Repeatability
±0.01°C
Heater
700 Watts @ 115V (230V) Nominal
Access Opening 6.8" x 4.7" (172 x 119 mm)
Immersion Depth 18" (457 mm) without liquid-in-glass thermometer cal kit
19" (482 mm) with liquid-in-glass thermometer cal kit
Wetted Parts 304 Stainless Steel
Power*
115 VAC (±10%), 60 Hz, 16 A, 1660 VA
[230 VAC (±10%), 50 Hz, 8 A, 1450 VA, optional]
Note: If the voltage is outside ±10%, the compressor may be damaged.
Check the back panel label for the correct voltage and frequency prior to
energizing the instrument.
System Fuse
115V: 20A 250V slow blow
230V: 10A 250V slow blow
Volume
4.2 gal. (15.9 liters)
Weight
150 lb. (68 kg)
Size (w x f–b x h)
14" W x 31" D x 42" H (356 x 788 x 1067mm); 37" (940 mm) from floor to
tank access opening
Safety
OVERVOLTAGE (Installation) CATEGORY II, Pollution Degree 2 per
IEC 1010-1
Refrigeration R-507 single stage
Interface Package RS-232 included, IEEE-488 optional
*Rated at listed 115 V (or optional 230 V).
