7341
Users Guide
4-4
moderate bath temperatures, clean distilled water works well. Carefully pour the fluid
into the bath tank through the large rectangular access hole above the tank avoiding
spilling any fluid.
Caution
When filling the tank, ensure the immersion coils are
completely covered. DO NOT FILL ABOVE THE STIR BAFFLE.
See Figure 4-1.
MIN FILL
Maximum Fill Level
Top of Baffle
Minimum Fill
Level Line
haz001.eps
Figure 4-1. Stir Baffle Fill Levels
