8270A/8370A
Operators Manual
30
Table 11. Graph
2
1
3
huo014.e
s
Item Indicator/Name Function
Graph
Scalable graph that shows the current pressure and historical pressure
behavior for up to 96 hours of elapsed time. This graph is an
informational tool only and cannot be saved.
Zooms Magnifies the graph by adjusting the time scale.
Time Scale Shows the time scale of the graph.
