High-Pressure Modular Controller
Main Menu
31
Table 12. Tasks
1
2
5
3
4
6
huo013.eps
Item Indicator/Name Function
Leak Test
Opens a menu to configure and do a leak test on the system. See
Leak Test.
Switch Test Preprogrammed task to test a pressure switch dead band.
Exercise Opens a menu to configure and exercise a DUT. See Exercise.
D Program
Automated testing interface to make, edit, modify, save, and run a
user-configured automated test. See Program.
E
CPS Cleanout
(Disabled when
CPS is OFF in the
Setup Menu)
Predefined sequence that cleans out the CPS with low pressure.
Useful after testing a very dirty DUT where cross contamination
could be a factor.
F
Purge
(Disabled when
CPS is OFF in the
Setup Menu)
Opens a menu to configure and purge the DUT and CPS. See Purge
(if CPS is installed).
