917X Series Metrology Wells
Getting Started
menu. If a parameter is entered or changed and “EXIT” is pressed before “ENTER”, the change
will be canceled. During some operations the “EXIT” key may be used to cancel the operation. If
a cutout condition exists, press the “EXIT” key to access the Cutout menu. To reset the cutout,
select the “RESET CUTOUT” parameter and select “YES” using the 4 or 5 keys. Press
“ENTER” to reset the Cutout.
°C/°F (10)
The “C/F” key allows the user to change the display units from Celsius to Fahrenheit and vice-
versa while viewing the main screen.
Up/Down (21)Arrows (11)
The up and down arrow keys have three functions: move the cursor through a list of parameters in
a window, scroll through parameters list that is longer than can be displayed, and, while viewing
the main screen, change the contrast of the display.
Note: Parameter entry will abort if the up or down arrow key is pressed before “ENTER”.
Therefore, the up or down arrow keys can be used to cancel a parameter change.
Left/Right (4 5) Arrows (11)
The left and right arrow keys have three functions: move from digit to digit while editing a
parameter, select or change an option for some parameters, and change focus from control to
reference or from reference to control. Remember, “ENTER” must always be pressed to save a
new value or option selected.
Accessories
• 9170-CASE, Case, 9170-3 Carrying
• 9170-INSA, Insert, A, 9170, miscellaneous holes
• 9170-INSB, Insert, B, 9170, comparison holes
• 9170-INSC, Insert, C, 9170, four 0.25 in holes
• 9170-INSD, Insert, D, 9170, metric, miscellaneous holes
• 9170-INSE, Insert, E, 9170, metric, 0.25 in reference, miscellaneous holes
• 9170-INSF, Insert, F, 9170, metric, 0.25 in reference, comparison holes
• 9170-INSG, Insert, G, 9170, EA testing
• 9170-INSY, Insert, Custom, 9170
• 9170-INSZ, Insert, Blank, 9170
• 9171-INSA, Insert, A, 9171, miscellaneous holes
• 9171-INSB, Insert, B, 9171, comparison holes
• 9171-INSC, Insert, C, 9171, four 0.25 in holes
9171-INSD, Insert, D, 9171, metric miscellaneou• s holes
24
