5
F
D
E
W*
B
C
L
K
A
G
M
J
H
I
SC-APC
GPU209.EPS
Figure 1. Connectors, Keys, and LEDs (Versiv 2 shown)
J
: Press to go to the home screen.
K
Connector for the AC adapter. Versiv: The LED is red when the battery
charges, and green when the battery is fully charged. The LED is yellow if
the battery will not charge.
L
RJ45 connector: Lets you connect to a network for access to Fluke
Networks cloud services.
M
Decal with laser
safety information:
WWarning*
Do not look directly into
optical connectors. Some
sources emit invisible
radiation that can cause
permanent damage to your
eyes.
